The 205 Manifold Mold is a precision-engineered fluid distribution solution tailored for centralized multi-circuit flow management in heating, plumbing, and light industrial systems. Crafted from robust metallic alloy, it integrates a 3/4″ main inlet with 2–5 parallel 16mm-diameter outlets, each governed by a blue knob valve. This design enables precise flow regulation across multiple branches, streamlining system installation and operation.
| Model | Main Inlet | Branch Details | Circuit Quantity |
|---|
| 3/4″×2 hole 16mm | 3/4″ male thread | 2×16mm outlets (blue knobs) | 2 |
| 3/4″×3 hole 16mm | 3/4″ male thread | 3×16mm outlets (blue knobs) | 3 |
| 3/4″×4 hole 16mm | 3/4″ male thread | 4×16mm outlets (blue knobs) | 4 |
| 3/4″×5 hole 16mm | 3/4″ male thread | 5×16mm outlets (blue knobs) | 5 |
- Material: Corrosion-resistant brass alloy (withstands 16 bar pressure, operating temperature: -20°C to 120°C).
- Blue Knob Fine Tuning: Each branch’s blue rotary knob enables gradual flow adjustment (unlike binary on/off valves), perfect for balancing hydronic heating or metering fluid in precision systems.
- 16mm Flow Optimization: The 16mm-diameter outlets ensure uniform flow distribution across 2–5 circuits, minimizing pressure loss and maximizing efficiency.
- Compact Multi-Branch Design: Consolidates up to 5 branches into a single unit, slashing pipeline clutter and installation time by 30% compared to standalone valves.
- Durable Construction: Brass composition resists corrosion from aggressive fluids (e.g., chlorinated water, glycol coolants) and mechanical wear, delivering a 15+ year service life.
- Hydronic Underfloor Heating: Distributes hot water to 2–5 zones, with knob valves allowing precise temperature balancing for each area.
- Fontanería comercial: Manages water supply to multiple fixtures (sinks, showers, outdoor taps) in hotels/offices, enabling easy flow adjustment.
- Industrial Cooling Loops: Controls coolant distribution in machinery with 2–5 parallel circuits, preventing overheating and supporting system expansion.
- Precision Control: Blue knobs enable gradual flow adjustment (vs. on/off levers), critical for applications like radiant heating or lab fluid metering.
- Scalability: Available in 2–5 circuit configurations, adapting to projects of all sizes—from homes to commercial complexes.
- Visual Clarity: Distinctive blue knobs reduce misoperation risks in complex systems, enhancing usability.
- Leak-Proof Sealing: Precision-machined valve seats and threads ensure zero leakage, safeguarding against water damage and downtime.
Achieve precise, scalable fluid distribution with a manifold that combines fine-tuning, durability, and compact design. Explore specs or request a quote at [
brand-official-site.com] (replace with actual brand URL).
